KTCF
|
SIZE |
最大孔径 (mm) |
尺寸(mm) |
||||
|
A |
B |
C |
D min |
G |
||
|
KTCF 30 |
85 |
185 |
73 |
115 |
118.8 |
15.4 |
|
KTCF 42 |
100 |
210 |
85 |
138 |
134.8 |
15.4 |
|
KTCF 65 |
110 |
225 |
95 |
150 |
149.3 |
15.4 |
|
KTCF135 |
120 |
280 |
108 |
166 |
181.3 |
19.0 |
|
KTCF 200 |
140 |
327 |
120 |
201 |
225.2 |
20.5 |
|
KTCF 270 |
180 |
381 |
160 |
243 |
251.2 |
24.7 |
|
KTCF 400 |
200 |
407 |
170 |
265 |
276.6 |
25.0 |
|
KTCF 635 |
220 |
458 |
185 |
295 |
316.0 |
33.5 |
表中B及D尺寸，可根据客户要求而更改。
|
适配盘规格尺寸（英寸） |
|||||||
|
SIZE |
OD |
SAE BLOTING |
HD BOLTING |
||||
|
BC |
HOLE QTY |
HOLE SIZE |
BC |
HOLE QTY |
HOLE SIZE |
||
|
10 |
10.375 |
9.625 |
6 |
13/32 |
9.500 |
8 |
12/32 |
|
12 |
12.375 |
11.625 |
8 |
13/32 |
11.500 |
8 |
17/32 |
|
14 |
13.875 |
13.125 |
8 |
13/32 |
12.500 |
8 |
21/32 |
|
18 |
18.375 |
17.250 |
8 |
17/32 |
16.750 |
8 |
25/32 |
|
20 |
20.375 |
19.250 |
8 |
17/32 |
18.500 |
8 |
29/32 |
|
22 |
22.500 |
21.375 |
6 |
21/32 |
20.500 |
8 |
1-1/32 |
|
26 |
26.500 |
25.250 |
12 |
21/32 |
24.500 |
12 |
1-1/32 |
|
28 |
28.875 |
27.250 |
12 |
25/32 |
26.875 |
12 |
1-1/32 |
